47RH Clutch Packs Help
Alright, I figured this would be easier to make a new thread. I've got a 47RH, doing overhaul. I've got RGPZ-47 Raybestos kit, it has 10 forward 0.062 5 overdrive .086 10 overdrive direct .061 I need all new steels, should I get the stmchry04k, which has 7 forward .086 4 overdrive .069 9 overdrive direct .054 OR Do I need to get the RCP96-113, which has waived direct, so I would also need waived direct steels? Or do I need to get GPZ-4748?? I know I have coned OD section steel when i took them out. The So confusing, I just need to know which steels & frictions to get in GPZ version (Kohlene is fine but not required).
47RH question and 12 valve dip stick
1) I thought I heard about a substitute dip stick tube, what can I use to make a new dip stick tube for my 12 valve? 2) took apart 47rh I found, it seems like that’s excessive OD clutch clearance
47RH question and 12 valve dip stick
G56 rebuild part 2
Ok finally said enough dicking around, bearings have been here for 3 weeks, hunting or not this needs to be done. Sunday night drained tcase and tranny Removed front and rear driveshaft -I can’t believe it but even with 340k these u joints are fine including the cv on the front Monday night Supported tranny with atv jack and blocks of wood/ratchet straps Removed tcase and cross member Tuesday night Pulled granny and got it out. Checked primary shaft end play while cold -5 thou Split the cases Check out the bearings, they are done. I am sooo glad I did this. All gears look good so far
G56 rebuild part 2
Custom Stub shaft - California
Wondering if anyone knows any machine shops that are equipped to make a female - male involuted spline stub shaft. Most shops here with HAAS won’t take anything under 6K order, and I need just a few of those spline shafts. Let me know! Haven’t been able to find anything so far with about a dozen RFQs. I’m in Sacramento CA
G56 rebuild want to do it mysef
My transmission in my 06 has a lot of end play, and I’m fairly certain that my input shaft bearing is on its way out. It makes a racket sometimes when the clutch is let out in nuetral which sounds like a grinding/whirring noise. Other times it’s fine. I’ve watched a ton of videos on long range gear, among other hobbyists , but I have two questions that the videos just don’t answer. I’m looking at a total rebuild kit from all state gear, it’s about 1250 cndn but it comes with all bearings, and all of the syncros, plus a shim kit for end play. Anyone recommend this? Transmission has never seen work and it’s got 340k on it, shifting is fine with no grinding as it is. Second, no one talks about end play specs including the service manual. I have been told you want to shim the primary and secondary shafts to a preload of 2 thousands positive. So you find zero with your shims then shim an extra 2 thousands. They say this makes the transmission much quieter and in turn allows for aluminum case expansion after heating up, allowing the end play to stay tight. Advice is appreciated :)
