Using PEX Pipe With Your Outdoor Boiler Can Maximize Efficiency

𝐈𝐧𝐭𝐫𝐨𝐝𝐮𝐜𝐭𝐢𝐨𝐧

When using an outdoor boiler to heat your home, efficiency is essential. Insulated PEX pipe is one technique to make sure your system functions as efficiently as possible. We'll go into the advantages of utilizing PEX pipe with your outdoor boiler in this post, as well as how this adaptable material may save you money, time, and effort.

𝐔𝐧𝐝𝐞𝐫𝐬𝐭𝐚𝐧𝐝𝐢𝐧𝐠 𝐏𝐄𝐗 𝐏𝐢𝐩𝐞𝐖𝐡𝐚𝐭 𝐢𝐬 𝐏𝐄𝐗 𝐏𝐢𝐩𝐞?

PEX—short for Cross-Linked Polyethylene—has been gaining popularity in both the residential and commercial sectors. PEX pipe is made from cross-linked HDPE (high-density polyethylene). The HDPE is melted and continuously extruded into a tube to form a high-performing pipe suitable for a variety of potable and non-potable plumbing applications. It has also been overtaking copper and CPVC because of its flexibility compared to copper.

𝐏𝐄𝐗 𝐏𝐢𝐩𝐞'𝐬 𝐀𝐝𝐯𝐚𝐧𝐭𝐚𝐠𝐞𝐬 𝐟𝐨𝐫 𝐎𝐮𝐭𝐝𝐨𝐨𝐫 𝐁𝐨𝐢𝐥𝐞𝐫𝐬𝐃𝐮𝐫𝐚𝐛𝐢𝐥𝐢𝐭𝐲 𝐚𝐧𝐝 𝐀𝐝𝐚𝐩𝐭𝐚𝐛𝐢𝐥𝐢𝐭𝐲

PEX pipe's longevity is among its primary benefits. It can tolerate severe weather, stave against corrosion, and stay safe from freezing-related damage. Because of its flexibility, installation is also made simple, even in confined locations.

𝐓𝐡𝐞 𝐜𝐨𝐬𝐭-𝐞𝐟𝐟𝐞𝐜𝐭𝐢𝐯𝐞𝐧𝐞𝐬𝐬

Compared to more conventional materials like copper, PEX pipe is typically less expensive. Its simplicity of installation also helps save labor expenses, which makes it an affordable choice for homeowners.

𝐒𝐢𝐦𝐩𝐥𝐞 𝐓𝐨 𝐈𝐧𝐬𝐭𝐚𝐥𝐥

PEX pipes are less complicated to install than rigid materials since they are easily bent and moved around obstacles. The time and effort needed for setup can be greatly decreased by this ease of usage.

𝐃𝐢𝐟𝐟𝐞𝐫𝐞𝐧𝐭 𝐏𝐄𝐗 𝐏𝐢𝐩𝐞 𝐓𝐲𝐩𝐞𝐬 𝐟𝐨𝐫 𝐎𝐮𝐭𝐝𝐨𝐨𝐫 𝐁𝐨𝐢𝐥𝐞𝐫𝐬

PEX pipe is available in various varieties, each intended for a particular use. The three most popular varieties, PEX-A, PEX-B, and PEX-C, have different manufacturing procedures and degrees of flexibility.

𝐏𝐄𝐗-𝐀

Pex A tubing is the softest, most flexible tubing that can be found, and it has the highest level of cross-linking for the strongest possible chemical bond. Peroxide is used in its manufacturing. Because of its elasticity, which allows it to expand, particularly when exposed to freezing water, PEX-A tubing is suitable for burial.

Remember that there is still some risk associated with PEX-A tubing as it has a higher tendency to release chemicals into the water supply during the production process. This is the reason this kind is merely a close second when it comes to subterranean burial.

𝐏𝐄𝐗-𝐁

Concerning the three forms of PEX, PEX B tubing has the highest bursting pressure. Because of this, PEX-B tubing is the best option for burying and is also quite affordable, despite having a lower cross-link ratio and being less flexible than PEX-A. Thus, the PEX-B tubing ought to be your first option if you're set on burying a section of PEX tubing.

𝐏𝐄𝐗-𝐂

By far the most difficult PEX tubing to work with is PEX-C tubing since it is so stiff. Because of the irradiation technique used to make it, it cannot be buried. It follows that the tubing is more likely to bend and shatter when exposed to freezing conditions.

𝐈𝐧𝐬𝐭𝐚𝐥𝐥𝐚𝐭𝐢𝐨𝐧 𝐏𝐫𝐨𝐜𝐞𝐬𝐬

It's important to properly organize the process before beginning the installation. Take into account the way your property is laid out, the distance between your house and the boiler, and any obstructions that might affect the installation. Pipe cutters, crimping tools, insulation, fittings, PEX pipes, and other supplies are among the many tools and materials you will require. The installation process will go more quickly if everything is prepared before you begin.

𝐔𝐧𝐝𝐞𝐫𝐠𝐫𝐨𝐮𝐧𝐝 𝐈𝐧𝐬𝐮𝐥𝐚𝐭𝐞𝐝 𝐏𝐄𝐗 𝐈𝐧𝐬𝐭𝐚𝐥𝐥𝐚𝐭𝐢𝐨𝐧 𝐓𝐢𝐩𝐬:

● Dig your trench at least 2’ deep

● Place the cable supplying electricity to the boiler in the trench first

● Under Driveways – If burying insulated PEX under a driveway, observe these two important requirements: The trench should be at least FOUR FEET DEEP, and placed inside a 6” PVC sleeve.

● No Rocks Touching White Casing – When backfilling the trench, backfill with sand first. Do not allow any rocks to touch the white outer casing of the insulated PEX. Any rocks against the surface of ANY outer casing may, over time, penetrate with settling.

● USE END CAPS!

● Make sure there is a completely waterproof connection between the inside of the outdoor boiler where the pump is connected and the inside of the building. Do NOT cut the insulated PEX outer casing until it has been extended INSIDE the building at least.

𝐌𝐚𝐢𝐧𝐭𝐞𝐧𝐚𝐧𝐜𝐞 𝐚𝐧𝐝 𝐋𝐨𝐧𝐠𝐞𝐯𝐢𝐭𝐲

𝐑𝐞𝐠𝐮𝐥𝐚𝐫 𝐌𝐚𝐢𝐧𝐭𝐞𝐧𝐚𝐧𝐜𝐞 𝐓𝐢𝐩𝐬

To keep your PEX pipe system running smoothly, perform regular inspections and maintenance. Check for leaks, ensure the insulation is intact, and clean any debris that may accumulate around the pipe.

𝐓𝐫𝐨𝐮𝐛𝐥𝐞𝐬𝐡𝐨𝐨𝐭𝐢𝐧𝐠 𝐂𝐨𝐦𝐦𝐨𝐧 𝐈𝐬𝐬𝐮𝐞𝐬

If you encounter issues such as leaks or reduced efficiency, troubleshoot by inspecting the fittings, checking the insulation, and ensuring the pipe is properly installed.

𝐄𝐱𝐭𝐞𝐧𝐝𝐢𝐧𝐠 𝐭𝐡𝐞 𝐋𝐢𝐟𝐞 𝐨𝐟 𝐘𝐨𝐮𝐫 𝐏𝐄𝐗 𝐏𝐢𝐩𝐞 𝐒𝐲𝐬𝐭𝐞𝐦

By performing regular maintenance and addressing issues promptly, you can extend the life of your PEX pipe system, ensuring it continues to operate efficiently for years to come.

𝐂𝐨𝐦𝐩𝐚𝐫𝐢𝐧𝐠 𝐏𝐄𝐗 𝐰𝐢𝐭𝐡 𝐎𝐭𝐡𝐞𝐫 𝐏𝐢𝐩𝐢𝐧𝐠 𝐌𝐚𝐭𝐞𝐫𝐢𝐚𝐥𝐬

𝑷𝑬𝑿 𝒗𝒔. 𝑪𝒐𝒑𝒑𝒆𝒓

Copper has been a traditional choice for plumbing, but PEX offers several advantages, including lower cost, easier installation, and better resistance to freezing temperatures.

𝑷𝑬𝑿 𝒗𝒔. 𝑷𝑽𝑪

While PVC is another common plumbing material, PEX is more flexible and durable, making it a better choice for outdoor boiler systems.

𝐂𝐨𝐧𝐜𝐥𝐮𝐬𝐢𝐨𝐧

Using PEX pipe with your outdoor boiler can significantly enhance the system's efficiency, durability, and cost-effectiveness. Whether you're a homeowner looking to upgrade your heating system or a business seeking a reliable solution, PEX pipe offers numerous benefits that make it an excellent choice.
